• 1/3-inch 12-bit CMOS sensors (1920 x 1080 x 3)
• F13 sensitivity (50Hz)
• “23x Fujinon auto focus zoom lens with manual functions F1.6-3.0, 23x, f=4.1-94.3mm (35mm conversion: 29 to 667mm)”
• Optical image stabilizer
• SDXC/SDHC memory card recording (two slots for dual-backup, continuous recording)
• 50Mbps H.264 Extreme High Quality mode (XHQ)
• “Multiple encoding formats: * HD MPEG2 (35/25/19Mbps) * AVCHD 1920×1080 60i * 1080/60p recording capability * SD H.264”
• “Wide media format compatibility: * MOV (Final Cut Pro) * MP4 (XDCAM EX™) * AVCHD”
• High performance 2D DNR

Info

Camera Front-End Specifications

Image Sensor (inch)

1/3 CMOS

Number of Sensors

3

Mega Pixels

2,2

Gain in dB

-6 to 24

Sensitivity in F at 2000 Lux

F 13

Shutter speed

1/4 to 1/10000

White Balance modes

FAW, AWA, 3200K, 5600K, Manual

Color Matrix adjustment

Oui

Wide Dynamic Range Mode (WDR)

Oui

User selected function buttons

Oui, 11 (7 Buttons 4 Cross shaped)

User Customizes Menu

Oui

Optical Specifications

Lens mount

Internal

Optical Zoom X times

23

Lens F Number

1,6 to 3

Lens ratio from / to

4,1mm to 94,3mm

Lens ratio equivalent to 35mm

29mm to 667mm

Auto Focus

Oui

Special Auto Focus Features

Area Focus, Near/Far Modes, Face

Optical Image stabilization

Oui

Filter Diameter in mm

72mm

Build in ND Filters

3 Filters: 1/4, 1/16, 1/64

Memory for Zoom Position

Oui, In and end points, with acceleration set up

Recording Formats

Media

SDHC/SDXC

Media Class

Class 10

Recording slots

2

Encoder

MPEG2 / H.264

File Format MOV

Oui

File Format MP4

Oui

File Format AVCHD

Oui

Video Codec MPEG2 Long GOP

Oui

Video Codec AVCHD

Oui

Video Codec H264 (SD)

Oui

Simultaneous recording on 2 cards

Oui

Recording Resolution Formats

Resolution 1920 x 1080

Oui, 60p/50p/30p/25p/24p/60i/50i

Resolution 1440 x 1080

Oui, 60i/50i

Resolution 1280 x720

Oui, 60p/50p/30p/25p/24p

Recording Data rate 1

19Mbps(SP), 25Mbps(SP), 35Mbps(HQ)

Recording Data rate 2

5,9,18,24,28Mbps (AVCHD)

Recording Data rate 3

35Mbps (UHQ)

Recording Data rate 4

50Mbps (XHQ)

SD Recording

Oui

Over / Under Crank

Oui

Pre Rec (retro) recording

Oui, 20 sec.

Clip Trimming

Oui

Audio Channels

2

Audio Recording modes

LPCM 2ch, 48 kHz/16 bit (MPEG-2 Long GOP/H.264), AC3(AVCHD)

Audio Filters

Oui, Wind-Cuts, Limiters, Gains

Audio Equalizer

Oui, Graphical

IN-OUT´s Connections

OUT HDSDI

Oui, 1080i 1,5 GBit

OUT HDSDI Format max.

1080i/60/50 8Bit 4:2:2

OUT HDMI

Oui

OUT HDMI Format max.

1920×1080 60/50p 8 Bit 4:2:2

OUT AV

Oui, 3.5mm mini jack

OUT Audio Line

Oui, AV out

OUT Audio Headphone

Oui, 2.5 mm mini jack

IN Audio XLR MIC/LINE

Oui, 2 CH with +48 V Mic and Line support

IN Audio AUX

Oui, 3.5 mm mini jack

Build in Microphones

Oui, Stereo MIC

Time code IN/OUT

Oui

Wired remote IN

Oui, 2.5mm mini jack LANC

USB Data Exchange (Storage)

Oui

EVF and LCD

Operation Panel Type

LCD

Operation Panel Resolution

920K

Operation Panel Size diagonal in inch

3,5

Electronic Viewfinder (EVF) Type

LCOS

Electronic Viewfinder (EVF) Resolution

1,22 Mp

Electronic Viewfinder (EVF) Size diagonal in inch

0,45

Power and Enviroment Spec´s

Power AC

Oui, AC/DC Adapter

Power DC

Oui, 12 Volt, Battery 7,4V

Battery types

SSL-JVC50 / SSL-JVC75 IDX

Consommation

Approximate 10W with VF in REC mode, default settings

Operation Temperature in Celsius degrees

0 to 40

Storage Temperature in Celsius degrees

-20 to 50

Operation Humidity in %

30 to 80

Storage Humidity under %

85

Mechanical Informations

Weight in kg

2.4 include battery

Measurements (WxHxD) in mm

W 178 x H 198 x D 416

Include Package

Battery

Oui, 1 x SSL-JVC50

AC/DC adapter

Oui, AC Adapter

Cable 1

Oui, Power cord

Instructions

Oui

Logiciels

Oui, Clip Manager

Additional s

Oui, eye cap

General Editing Note

NOTE:

Simulated pictures.The values for weight and dimensions are approximate .E.&O.E. Design and specifications subject to change without notice.
